BMW X5 E70 Air bag cash Reset Chip Location

In the BMW X5 E70 (model years 2007–2013), the airbag control module, also known as the SRS (Supplemental Restraint System) module, is located beneath the center console, near the rear seat vents.

Steps to Access the Airbag Control Module:

1. Disconnect the Battery:
   • Before beginning any work, disconnect the vehicle’s battery to prevent accidental airbag deployment.
   • Remove the negative cable first, followed by the positive cable.
2. Access the Rear of the Center Console:
   • Remove the rear seat vents and the tray under the center console lid to expose the area beneath.
3. Locate the Module:
   • The airbag control module is situated near the handbrake lever, under the center console.
   • It has a bright yellow connector, which is standard for airbag system components.
4. Unbolt and Disconnect:
   • Once the module is accessible, use appropriate tools to unbolt it from its mounting position.
   • Carefully disconnect the wiring harnesses connected to the module, noting their positions for reinstallation.

Important Considerations:

• Safety Precautions:
  • Always disconnect the battery and wait for at least 3 minutes before working on the airbag system to ensure residual power is discharged.
  • Handle the airbag module and related components with care to avoid triggering the airbags.
• Professional Assistance:
  • If you’re not experienced with automotive safety systems, it’s advisable to seek assistance from a qualified technician to ensure proper handling and maintenance.

For a visual guide on accessing the airbag control module in a BMW X5 E70, you may find the following video helpful:
