CADILLAC CTS Air bag cash Reset Chip Location

In the Cadillac CTS, the airbag control module, also known as the SRS (Supplemental Restraint System) module, is typically located beneath the center console, between the front seats.

Steps to Access the Airbag Control Module:

1. Disconnect the Battery:
   • Before beginning any work, disconnect the vehicle’s battery to prevent accidental airbag deployment.
   • Remove the negative cable first, followed by the positive cable.
2. Remove the Center Console:
   • Carefully detach any trim pieces and screws securing the center console.
   • Lift the console to expose the area beneath.
3. Locate the Module:
   • The airbag control module is situated near the gear stick, under the center console.
   • It has a bright yellow connector, which is standard for airbag system components.
4. Unbolt and Disconnect:
   • Once the module is accessible, use appropriate tools to unbolt it from its mounting position.
   • Carefully disconnect the wiring harnesses connected to the module, noting their positions for reinstallation.

Important Considerations:

• Safety Precautions:
  • Always disconnect the battery and wait for at least 3 minutes before working on the airbag system to ensure residual power is discharged.
  • Handle the airbag module and related components with care to avoid triggering the airbags.
• Professional Assistance:
  • If you’re not experienced with automotive safety systems, it’s advisable to seek assistance from a qualified technician to ensure proper handling and maintenance.

For a visual guide on locating and removing the airbag control module in a Cadillac CTS, you may find the following video helpful
